Aidite® CT scan

SIMPLE, SAFE, ACCESSIBLE

Now and only available in France with LYRA ETK

The best-value solution for your first digital impressions!

Tested and validated by LYRA ETK, the No. 1 distributor and installer of intra-oral scanners in France since 2015, this CT scan offers all the features you need for your digital impressions and performance on a par with the best brands.

Request this scanner

Clinical test

Dr. MARKOVIC – 9/09/2023 – iPhysio case on tooth 22 : screw-retained crown on implant

The scanner Cameo Elegant 3 presents many pros : good scan, acquisition speed, very good color rendering obvious advantage for iPhysio cases, well balanced in hand, pleasant light weight, easy to use, ergonomic interface.

Be aware that the scanner doesn't have a wireless available.

Cameo Elegant 3 CT scanner

  • Lightweight and ergonomic.
  • For use in implantology, orthodontics and prosthetics.
  • Allows full arch CT scans and 3-shape post CT scans in endodontics.
  • iPhysio compatible.
  • Compatible with 3 shape and exocad design software.
  • User interface in French.

Your CT scan for €13,188

Request this scanner

TECHNICAL SPECIFICATIONS AIDITE® CAMEO ELEGANT 3

Scan Field
Standard scanner tip:16 mm x 12 mm * 22 mm
Mini scanner tip: 12 mm x 9 mm x 22 mm
Scan Depth
-2-20 mm from exit surface of tip
Scan Principle
Non-contact scanner with structured light
Dimension (L x W x H)
281 mm x 33 mm * 46 mm
Weight
240 + 10 g (without cables)
Output
STL, OBJ, PLY
Connector
USB 3.0
Power Input
12V DC/3A
Recommended PC Configuration
CPU
Intel Core i7-8700 or higher
Memory
16 GB or higher
Hard Disk Drive
256 GB SSD or above
Graphic Card (GPU)
NVIDIA® RTX 2060 668 or higher
Operating System
Windows 10 Professional (64-bit) or later versions of Windows operating system
Display Resolution
1920 x 1080, 60Hz or higher
I/O Ports
More than 2 type-A USB 3.0 (or higher) ports
Excellent precision
Request a performance test
Excellent data collection
Download the brochure
